View 2n7002w datasheet:

2n7002w2n7002w

UNISONIC TECHNOLOGIES CO., LTD 2N7002W Preliminary Power MOSFET 300mA, 60V N-CHANNEL POWER MOSFET DESCRIPTION The UTC 2N7002W uses advanced technology to provide excellent RDS(ON), low gate charge and operation with low gate voltages. This device is suitable for use as a load switch or in PWM applications. FEATURES * High Density Cell Design for Low R . DS(ON)* Voltage Controlled Small Signal Switch * Rugged and Reliable * High Saturation Current Capability SYMBOL ORDERING INFORMATION Ordering Number Pin Assignment Package Packing Lead Free Halogen Free 1 2 3 2N7002WL-AL3-R 2N7002WG-AL3-R SOT-323 S G D Tape Reel MARKING 3PG: Halogen Free L: Lead Freewww.unisonic.com.tw 1 of 3 Copyright 2012 Unisonic Technologies Co., Ltd QW-R502-537.b 2N7002W Preliminary Power MOSFET ABSOLUTE MAXIMUM RATINGS (TA=25C, unless otherw
