View 2n7076 datasheet:

2n70762n7076

isc N-Channel MOSFET Transistor 2N7076DESCRIPTIONDrain Current I =28A@ T =25D CDrain Source Voltage-: V =200V(Min)DSSMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationAPPLICATIONSDesigned for use in switch mode power supplies and generalpurpose applications.ABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL ARAMETER VALUE UNITV Drain-Source Voltage (V =0) 200 VDSS GSV Gate-Source Voltage 20 VGSI Drain Current-continuous@ TC=25 28 ADP Total Dissipation@TC=25 150 WtotT Max. Operating Junction Temperature -55~150 jT Storage Temperature Range -55~150 stgTHERMAL CHARACTERISTICSSYMBOL PARAMETER MAX UNIT/WR Thermal Resistance,Junction to Case 0.83th j-c/WR Thermal Resistance,Junction to Ambient 50th j-a1isc websitewww.iscsemi.cn isc & iscsemi is registered tradem
