View 2pb710asl datasheet:

2PB710ARL; 2PB710ASL50 V, 500 mA PNP general-purpose transistorsRev. 01 29 October 2008 Product data sheet1. Product profile1.1 General descriptionPNP general-purpose transistors in a small SOT23 (TO-236AB) Surface-MountedDevice (SMD) plastic package.Table 1. Product overviewType number[1] Package NPN complementNXP JEDEC2PB710ARL SOT23 TO-236AB 2PD602ARL2PB710ASL 2PD602ASL2PB710ARL/DG SOT23 TO-236AB 2PD602ARL/DG2PB710ASL/DG 2PD602ASL/DG[1] /DG: halogen-free1.2 Features General-purpose transistors Two current gain selections AEC-Q101 qualified Small SMD plastic package1.3 Applications General-purpose switching and amplification1.4 Quick reference dataTable 2. Quick reference dataSymbol Parameter Conditions Min Typ Max UnitVCEO collector-emitter voltage open base - - -50 VIC collector current - - -500 mA[1]hFE DC current gain V
