View 2sa1011 3ca1011 datasheet:

2SA1011(3CA1011) PNP /SILICON PNP TRANSISTOR :100W Purpose: High voltage switching, AF power amplifier, 100W output predriver applications. : 2SC2344(3DA2344) Features: complementary pair with 2SC2344(3DA2344). /Absolute maximum ratings(Ta=25) Symbol Rating Unit V -180 V CBO V -160 V CEO V -6.0 V EBO I -1.5 A C I -3.0 A CPP 2.0 W CP (T =25) 25 W C CT 150 j T -55150 stg /Electrical characteristics(Ta=25) Rating Symbol Test condition Unit Min Typ Max V I =-1.0mA I =0 -180 V CBO C EV I =-1.0mA I =0 -160 V CEO C BV I =-10mA I =0 -6.0 V EBO E CI V =-120V I =0 -10
