View 2sa1012 datasheet:

2SA1012(PNP) TO-220 TransistorTO-2201. BASE 2. COLLECTOTR3. EMITTER 3 21FeaturesHIGH CURRENT SWITCHING APPLICATIONS. Low Collector Saturation Voltage : VCE(SAT) = - 0.4V(MAX) at IC= - 3A High Speed Swithing Time : tstg = 1.0us (Typ.) Complementary to 2SC2562 MAXIMUM RATINGS (TA=25 unless otherwise noted) Symbol Parameter Value UnitsVCBO Collector-Base Voltage -60 V Dimensions in inches and (millimeters)VCEO Collector-Emitter Voltage -50 V VEBO Emitter-Base Voltage -5 V IC Collector Current -Continuous -5 A PC Collector Power Dissipation 2 W Tj Junction Temperature 150 Tstg Storage Temperature Range -55-150 ELECTRICAL CHARACTERISTICS(Tamb=25 unless otherwise specified) Parameter Symbol Test conditions MIN TYP MAX UNIT Collector-base breakdown voltage V(BR)CBO IC =-1mA, IE=0 -60 VCollector-emitter br
