View 2sa1012 datasheet:

UNISONIC TECHNOLOGIES CO., LTD 2SA1012 PNP SILICON TRANSISTOR HIGH CURRENT SWITCHING APPLICATION FEATURES *Low Collector Saturation Voltage V =-0.4V(max.) At I =-3A CE(SAT) C*High Speed Switching Time: t =1.0s (Typ.) S*Complementary To 2SC2562 ORDERING INFORMATION Ordering Number Pin Assignment Package Packing Lead Free Halogen Free 1 2 32SA1012L-x-TA3-T 2SA1012G-x-TA3-T TO-220 B C E Tube 2SA1012L-x-TF3-T 2SA1012G-x-TF3-T TO-220F B C E Tube 2SA1012L-x-TM3-T 2SA1012G-x-TM3-T TO-251 B C E Tube 2SA1012L-x-TN3-R 2SA1012G-x-TN3-R TO-252 B C E Tape Reel Note: Pin Assignment: B: Base C: Collector E: Emitter MARKING www.unisonic.com.tw 1 of 4 Copyright 2018 Unisonic Technologies Co., Ltd QW-R203-015.M 2SA1012 PNP SILICON TRANSISTOR ABSOLUTE MAXIMUM RATINGS (TA=25C, unless otherwise specified) PARAMETER SYMBOL RATINGS
