View 2sa1015 datasheet:

2SA1015 Rev.E Mar.-2016 DATA SHEET / Descriptions TO-92 PNP Silicon PNP transistor in a TO-92 Plastic Package. / Features ,, h ,, 2SC1815 FEHigh voltage and high current, excellent hFE linearity, low noise, complementary pair with 2SC1815. / Applications ,Audio frequency general purpose, driver stage amplifier applications. / Equivalent Circuit / Pinning 1 2 3 PIN1Base PIN 2Collector PIN 3Emitter / hFE Classifications & Marking hFE Classifications O Y GRSymbol hFE Range 70~140 120~240 200~400http://www.fsbrec.com 1 / 6 2SA1015 Rev.E Mar.-2016 DATA SHEET / Absolute Maximum Ratings(Ta=25)
