View 2sa1015 datasheet:

2SA1015BIPOLAR TRANSISTOR (PNP)FEATURES High current And High voltage Excellent h LinearityFE Low Noise Surface Mount device Complementary to 2SC1815SOT-23MECHANICAL DATA Case: SOT-23 Case Material: Molded Plastic. UL flammability Classification Rating: 94V-0Weight: 0.008 grams (approximate)MAXIMUM RATINGS (T = 25C unless otherwise noted)AParameter Symbol Value UnitCollector-Base Voltage V -50 VCBOCollector-Emitter Voltage V -50 VCEOEmitter-Base Voltage V -5 VEBOCollector Current IC -150 mACollector Power DissipationPC 200 mWThermal Resistance From Junction To Ambient R 625 C/WJAJunction Temperature TJ 150 CStorage Temperature TSTG -55 ~+150 CELECTRICAL CHARACTERISTICS (T = 25C unless otherwise specified)AParameter Symbol Min Typ Max Unit ConditionsCollector-base breakdown volt
