View 2sa1015 datasheet:

UNISONIC TECHNOLOGIES CO., LTD 2SA1015 PNP SILICON TRANSISTOR LOW FREQUENCY PNP AMPLIFIER TRANSISTOR FEATURES * Collector-Emitter Voltage: BV =-50V CEO1* Collector Current up to 150mA * High h Linearity FETO-92* Complement to UTC 2SC1815 ORDERING INFORMATION Ordering Number Pin Assignment Package Packing Lead Free Plating Halogen Free 1 2 3 2SA1015L-xx-T92-B 2SA1015G-xx-T92-B TO-92 E C B Tape Box2SA1015L-xx-T92-K 2SA1015G-xx-T92-K TO-92 E C B BulkNote: Pin Assignment: E: Emitter C: Collector B: Base MARKING www.unisonic.com.tw 1of 4 Copyright 2014 Unisonic Technologies Co., LTD QW-R201-004.D 2SA1015 PNP SILICON TRANSISTOR ABSOLUTE MAXIMUM RATING (TA=25C, unless otherwise specified) PARAMETER SYMBOL RATINGS UNITCollector-Base Voltage V -50 VCBOCollector-Emitter Voltage V -50 VCEOEmitter-Base Voltage V -5 V
