2SA10152 SA10 15 TRANSISTOR (PNP) FEATURES SOT-23 High voltage and high current Excellent hFE Linearity1BASE Complementary to C18152EMITTER 3COLLECTOR OAbsolute Maximum Ratings (Ta = 25 C)Parameter Symbol Value Unit -50 Collector Base Voltage VCBO V -50 Collector Emitter Voltage VCEO V -5 Emitter Base Voltage VEBO V Collector Current IC -150 mA Base Current IB mA -50Power Dissipation Ptot 200 mW O Junction Temperature Tj 150 CO Storage Temperature Range TS - 65 to +150 COCharacteristics at Ta = 25 C Parameter Symbol Min. Max. Unit DC Current Gain at -VCE = 6 V, -IC = 2 mA Current Gain Group hFE 70 140 - O hFE 120 240 - YhFE 200 400 - Gat -VCE = 6 V, -IC = 150 mA hFE 25 - - Collector Base Cutoff Current - 0.1 ICBO - A at -VCB = 50 V Emitter Base Cutoff Current - 0.1 IEBO - A at
