View 2sa1832 datasheet:

SMD Type TransistorsPNP Transistors2SA1832SOT-523 U nit: m m+0.11.6 -0.1+0.11.0 -0.1+0.050.2 -0.05 0.150.052 1 Features High voltage and high current Excellent hFE linearity3 Complementary to 2SC47380.30.05+0.10.5-0.11. Base2. Emitter3. Collecter Absolute Maximum Ratings Ta = 25Parameter Symbol Rating Unit Collector - Base Voltage VCBO -50 Collector - Emitter Voltage VCEO -50 V Emitter - Base Voltage VEBO -5 Collector Current - Continuous IC -150 mA Collector Power Dissipation PC 100 mW Thermal Resistance Junction to Ambient RJA 125 /W Junction Temperature TJ 125 Storage Temperature range Tstg -65 to 125 Electrical Characteristics Ta = 25Parameter Symbol Test Conditions Min Typ Max Unit Collector- base breakdown voltage VCBO Ic= -100 A IE=0 -50 Collector- emitter bre
