View 2sa1834 datasheet:

2SA1834 Transistors Low VCE(sat) Transistor (Strobe flash) (-20V, -10A) 2SA1834 External dimentions (Unit : mm) Features 1) Low saturation voltage, CPT36.55.1typically VCE(sat) = -0.16V at IC / IB= -4A / -50mA. 2.30.52) High current capacity, typically IC= 10A for DC operation and 15A for 10ms pulse. 3) Complements the 2SC5001. 0.75 Packaging specifications and hFE 0.65Type 2SA18340.92.3(1)Base2.3(1) (2) (3)0.5Package CPT3(2)Collector1.0hFE RS (3)EmitterCode TLBasic ordering unit (pieces) 2500 Absolute maximum ratings (Ta=25C) Parameter Symbol Limits Unit Collector-base voltageVCBO -30 VCollector-emitter voltageVCEO -20 VEmitter-base voltageVEBO -6 VIC -10 ACollector currentICP -15 A Base currentIB -2A1 WCollector power dissipationPC10 W(Tc=25C)Junction temperatureT
