View 2sa1837 datasheet:

2SA1837 TOSHIBA Transistor Silicon PNP Epitaxial Type 2SA1837 Power Amplifier Applications Unit: mmDriver Stage Amplifier Applications High transition frequency: fT = 70 MHz (typ.) Complementary to 2SC4793 Absolute Maximum Ratings (Tc = 25C) Characteristics Symbol Rating UnitCollector-base voltage VCBO -230 VCollector-emitter voltage VCEO -230 VEmitter-base voltage VEBO -5 VCollector current IC -1 ABase current IB -0.1 ATa = 25C 2.0 Collector power PC W dissipation Tc = 25C 20 JEDEC Junction temperature Tj 150 CJEITA Storage temperature range Tstg -55 to 150 C TOSHIBA 2-10R1ANote: Using continuously under heavy loads (e.g. the application of high Weight: 1.7 g (typ.) temperature/current/voltage and the significant change in temperature, etc.) may cause this product to decrease in the reliability signifi
