View 2sa636 2sa636a datasheet:

JMnic Product Specification Silicon PNP Power Transistors 2SA636 2SA636A DESCRIPTION With TO-202 package Complement to type 2SC1098/1098A High breakdown voltage High transition frequency APPLICATIONS For audio frequency power amplifier and low speed switching applications PINNING(see Fig.2) PIN DESCRIPTION1 Base 2 CollectorFig.1 simplified outline (TO-202) and symbol3 EmitterAbsolute maximum ratings (Ta=25) SYMBOL PARAMETER CONDITIONS VALUE UNITVCBO Collector-base voltage Open emitter -70 V 2SA636 -45VCEO Collector-emitter voltage Open base V 2SA636A -60 VEBO Emitter-base voltage Open collector -5 V IC Collector current -3 A ICM Collector current-peak -5 AIB Base current -0.6 A TC=25 10 PT Total power dissipation W Ta=25 1.2 Tj Junction temperature 150 Tstg Storage temperature -55~150 JMnic Prod
