2SB7722SD882PNP / NPN Epitaxial Planar TransistorsTO-126P b Lead(Pb)-Free1.EMITTER2.COLLECTOR3.BASE123ABSOLUTE MAXIMUM RATINGS (Ta=25C)Rating Symbol PNP/2SB772 UnitNPN/2SD882VCEO -30 30 VdcCollector-Emitter VoltageVCBO -40 40 VdcCollector-Base VoltageVEBO -5.0 5.0 VdcEmitter-Base VoltageIC(DC) -3.0 3.0 AdcCollector Current(DC)IC(Pulse) -7.0 7.0 AdcCollector Current(Pulse)(1)IB(Pulse) AdcBase Current-0.6 0.6PD 1.0 WTotal Cevice Disspation Ta=25CPD 10 WTotal Cevice Disspation Tc=25CTj 150 CJunction TemperatureStorage, Temperture Tstg -55 to +150 CDevice Marking2SB772=B772 , 2SD882=D882ELECTORICAL CHARACTERISTICSCharacteristics Symbol Min Max UnitCollect-Emitter Breakdown Voltage (IC=-10/10 mAdc, IB=0) V(BR)CEO -30/30 - VdcCollect-Base Breakdown Voltage (IC=-100/100 Adc, IE=0) V(BR)CBO -40/40 - Vdc
