View 2sc2073 datasheet:

2SC2073NPN / Descriptions TO-220 NPN Silicon NPN transistor in a TO-220 Plastic Package. / Features PIN1Base , 2SA940 1 PIN 2Collector 2 3 Wide Safe Operating Area, complementary to 2SA940. PIN 3Emitter / Applications Power amplifier applications, vertical output applications. / Absolute Maximum Ratings(Ta=25) Parameter Symbol Rating Unit Collector to Base Voltage VCBO 150 VCollector to Emitter Voltage VCEO 150 VEmitter to Base Voltage VEBO 5.0 VCollector Current - Continuous IC 1.5 ABase Current - Continuous IB 0.5 APC 2.0 WCollector Power Dissipation PC(Tc=25) 25 WTj Junction Temperature 150 Tstg Storage Temperat
