View 2sc5600 datasheet:

DATA SHEETNPN SILICON RF TRANSISTOR2SC5600NPN SILICON RF TRANSISTORFLAT-LEAD 3-PIN THIN-TYPE ULTRA SUPER MINIMOLDFEATURES Low voltage operation, low phase distortion Ideal for OSC applications Flat-lead 3-pin thin-type ultra super minimold (t = 0.59 mm)ORDERING INFORMATIONPart Number Quantity Supplying Form2SC5600 50 pcs (Non reel) 8 mm wide embossed taping2SC5600-T1 3 kpcs/reel Pin 3 (collector) face the perforation side of the tapeRemark To order evaluation samples, consult your NEC sales representative (Unit sample quantity is 50 pcs).ABSOLUTE MAXIMUM RATINGS (TA = +25 C)Parameter Symbol Ratings UnitCollector to Base Voltage VCBO 9VCollector to Emitter Voltage VCEO 5.5 VEmitter to Base Voltage VEBO 1.5 VCollector Current IC 100 mANoteTotal Power Dissipation Ptot 200 mWJunction Temperature Tj 150 CStorage
