View 2sc6092ls datasheet:
Ordering number : ENA0834 2SC6092LSSANYO SemiconductorsDATA SHEETNPN Triple Diffused Planar Silicon TransistorColor TV Horizontal Deflection2SC6092LSOutput ApplicationsFeatures High speed. High breakdown voltage (VCBO=1500V). Adoption of high reliability HVP process. Adoption of MBIT process.SpecificationsAbsolute Maximum Ratings at Ta=25CParameter Symbol Conditions Ratings UnitCollector-to-Base Voltage VCBO 1500 VCollector-to-Emitter Voltage VCEO 700 VEmitter-to-Base Voltage VEBO 5 VCollector Current IC 8 ACollector Current (Pulse) ICP 20 A2.0 WCollector Dissipation PCTc=25C35 WJunction Temperature Tj 150 CStorage Temperature Tstg --55 to +150 CElectrical Characteristics at Ta=25CRatingsParameter Symbol Conditions Unitmin typ maxCollector Cutoff Current ICBO VCB=800V, IE=0A 10 ACollector Cutoff Curren
