View 2sc6098 datasheet:

Ordering number : ENA0413 2SC6098NPN Epitaxial Planar Silicon Transistor2SC6098High-Voltage Switching ApplicationsApplications DC / DC converter, relay drivers, lamp drivers, motor drivers, inverter.Features Adoption of FBET, MBIT process. High current capacitance. Low collector-to-emitter saturation voltage. High-speed switching. High allowable power dissipation.SpecificationsAbsolute Maximum Ratings at Ta=25CParameter Symbol Conditions Ratings UnitCollector-to-Base Voltage VCBO 120 VCollector-to-Emitter Voltage VCES 120 VCollector-to-Emitter Voltage VCEO 80 VEmitter-to-Base Voltage VEBO 6.5 VCollector Current IC 2.5 ACollector Current (Pulse) ICP 4 ABase Current IB 500 mA0.8 WCollector Dissipation PCTc=25C15 WJunction Temperature Tj 150 CStorage Temperature Tstg --55 to +150 CElectrical Characteristics a
