View 2sc945 datasheet:

2sc9452sc945

2SC945 Rev.E Mar.-2016 DATA SHEET / Descriptions TO-92 NPN Silicon NPN transistor in a TO-92 Plastic Package. / Features ,h FE High voltage, excellent hFE linearity. / Applications AF amplifier and low speed switching applications. / Equivalent Circuit / Pinning 1 2 3 PIN1Base PIN 2Collector PIN 3Emitter / hFE Classifications & Marking hFE Classifications R Q P KSymbol hFE Range 90~180 135~270 200~400 300~600http://www.fsbrec.com 1 / 6 2SC945 Rev.E Mar.-2016 DATA SHEET / Absolute Maximum Ratings(Ta=25) Parameter Symbol Rating Unit Collector to Base Voltage VCBO 60 VCollector to Emitter Voltage VCEO 50 VE
