View 2sd1691 datasheet:

UNISONIC TECHNOLOGIES CO., LTD 2SD1691 NPN SILICON TRANSISTOR LOW COLLECTOR SATURATION VOLTAGE 11LARGE CURRENT TO-220F1TO-220 FEATURES *High Power Dissipation 11*Complementary to 2SB1151 TO-251 TO-25211TO-126CTO-126 ORDERING INFORMATION Ordering Number Pin Assignment Package Packing Lead Free Plating Halogen Free 1 2 3 2SD1691L-x-TA3-T 2SD1691G-x-TA3-T TO-220 B C E Tube2SD1691L-x-TF1-T 2SD1691G-x-TF1-T TO-220F1 B C E Tube2SD1691L-x-TM3-T 2SD1691G-x-TM3-T TO-251 B C E Tube2SD1691L-x-TN3-T 2SD1691G-x-TN3-T TO-252 B C E Tape Reel2SD1691L-x-T60-K 2SD1691G-x-T60-K TO-126 E C B Bulk2SD1691L-x-T6C-K 2SD1691G-x-T6C-K TO-126C E C B BulkNote: Pin Assignment: B: Base C: Collector E: Emitter MARKING TO-220 / TO-220F1 / TO-251 / TO-252 TO-126 / TO-126C www.unisonic.com.tw 1 of 4 Copyright 2014 Unisonic Technologies Co.,
