View 2sd1804 datasheet:
Ordering number:EN2086BPNP/NPN Epitaxial Planar Silicon Transistors2SB1204/2SD1804High-Current Switching ApplicationsApplications Package Dimensions Relay drivers, high-speed inverters, converters, andunit:mmother general high-current switching applications.2045B[2SB1204/2SD1804]Features Low collector-to-emitter saturation voltage. High current and high fT. Excellent linearity of hFE. Fast switching time. Small and slim package making it easy to make2SB1204/2SD1804-applied sets smaller.1 : Base2 : Collector3 : Emitter4 : CollectorSANYO : TPunit:mm2044B[2SB1204/2SD1804]1 : Base2 : Collector3 : Emitter4 : CollectorSANYO : TP-FAAny and all SANYO products described or contained herein do not have specifications that can handleapplications that require extremely high levels of reliability, such as life-support
