View 2sd1886 datasheet:

Ordering number:EN2433NPN Triple Diffused Planar Silicon Transistor2SD1886Color TV Horizontal DeflectionOutput ApplicationsApplications Package Dimensions Color TV horizontal diflection output.unit:mm Color display horizontal deflection output.2039D[2SD1886]16.05.6Features3.43.1 High speed (tf=100ns). High breakdown voltage (VCBO=1500V). High reliability (adoption of HVP process).2.82.0 2.01.00.61 : Base1 2 32 : Collector3 : Emitter5.45 5.45SANYO : TO-3PMLSpecificationsAbsolute Maximum Ratings at Ta = 25CParameter Symbol Conditions Ratings UnitCollector-to-Base Voltage VCBO 1500 VCollector-to-Emitter Voltage VCEO 800 VEmitter-to-Base Voltage VEBO 6 VCollector Current IC 8 ACollector Current (Pulse) ICP 30 ACollector Dissipation PC 70 WJunction Temperature Tj 150 CStorage Temperature Tstg
