View 2sd2210 datasheet:

Transistor2SD2210Silicon NPN epitaxial planer typeFor low-voltage output amplificationUnit: mmFor mutingFor DC-DC converter1.5 0.14.5 0.11.6 0.2FeaturesLow collector to emitter saturation voltage VCE(sat).45Low ON resistance Ron.High foward current transfer ratio hFE.0.4 0.080.4 0.040.5 0.081.5 0.1Absolute Maximum Ratings (Ta=25C)3.0 0.15Parameter Symbol Ratings Unit3 2 1Collector to base voltage VCBO 25 VCollector to emitter voltage VCEO 20 VmarkingEmitter to base voltage VEBO 12 VPeak collector current ICP 1 A1:BaseCollector current IC 0.5 A2:Collector EIAJ:SC62Collector power dissipation PC* 1 W3:Emitter Mini Power Type PackageJunction temperature Tj 150 CMarking symbol : IKStorage temperature Tstg 55 ~ +150 C*Printed circuit board: Copper foil area of 1cm2 or more, and the board
