View 2sd2212 datasheet:

SMD Type TransistorsNPN Transistors2SD2212SOT-89Unit:mm1.70 0.1 Features Collector Current Capability IC=2A Collector Emitter Voltage VCEO=50VC0.42 0.10.46 0.1BR1 R21.BaseE2.CollectorR1 3.5kR2 300 3.Emitter Absolute Maximum Ratings Ta = 25Parameter Symbol Rating Unit Collector - Base Voltage VCBO 50 Collector - Emitter Voltage VCEO 50 V Emitter - Base Voltage VEBO 6 Collector Current - Continuous IC 2A Collector Current - Pulse ICP 30.5 Collector Power Dissipation PC W(Note.1) 2 Junction Temperature TJ 150 Storage Temperature Range Tstg -55 to 150Note.1 :Mounted on a 4040 0.7mm ceramic substrate Electrical Characteristics Ta = 25Parameter Symbol Test Conditions Min Typ Max Unit Collector- base breakdown voltage VCBO Ic= 100 A IE= 0 50 Collector- emitter breakdown voltage VC
