View 2sd2217 datasheet:

DATA SHEETDARLINGTON POWER TRANSISTOR2SD2217NPN SILICON EPITAXIAL TRANSISTOR (DARLINGTON CONNECTION)FOR LOW-FREQUENCY POWER AMPLIFIERS AND LOW-SPEED SWITCHINGThe 2SD2217 is a mold power transistor developed for low- PACKAGE DRAWING (UNIT: mm)frequency power amplifiers and low-speed switching. Thistransistor is ideal for direct driving from the IC out to drivers such aspulse motor drivers and relay drivers in OA and FA equipment.QUALITY GRADES StandardPlease refer to Quality Grades on NEC Semiconductor Devices(Document No. C11531E) published by NEC Corporation to knowthe specification of quality grade on the devices and itsrecommended applications.ABSOLUTE MAXIMUM RATINGS (Ta = 25C)Parameter Symbol Ratings UnitCollector to base voltage VCBO 300 VCollector to emitter voltage VCEO 300 VEmitter to base voltage VEBO 7VCollector
