View 2sd2494 datasheet:
Product Specification www.jmnic.com Silicon NPN Darlington Power Transistors 2SD2494 DESCRIPTION With TO-3PML package Complement to type 2SB1625 APPLICATIONS Audio, Series regulator General Purpose PINNING PIN DESCRIPTION1 Base 2 Collector3 EmitterFig.1 simplified outline (TO-3PML) and symbol Maximum absolute ratings(Tc=25) SYMBOL PARAMETER CONDITIONS VALUE UNITVCBO Collector-base voltage Open emitter 110 V VCEO Collector-emitter voltage Open base 110 V VEBO Emitter-base voltage Open collector 5 V IC Collector current 6 A IB Base current 1 APC Collectorl power dissipation TC=25 60 WTj Junction temperature 150 Tstg Storage temperature -55~150 JMnicProduct Specification www.jmnic.com Silicon NPN Darlington Power Transistors 2SD2494 CHARACTERISTICS Tj=25 unless otherwise specified SYMBOL PARAMETER C
