View 2sj107 datasheet:
2SJ107 TOSHIBA Field Effect Transistor Silicon P Channel Junction Type 2SJ107 For Audio Amplifier, Analog Switch, Constant Current Unit: mm and Impedance Converter Applications High input impedance: IGSS = 1.0 nA (max) (V = 25 V) GS Low R : R = 40 (typ.) DS (ON) DS (ON) Small package Complementary to 2SK366 Maximum Ratings (Ta == 25C) ==Characteristics Symbol Rating UnitGate-drain voltage VGDS 25 V Gate current IG -10 mADrain power dissipation PD 200 mWJunction temperature Tj 125 CStorage temperature range Tstg -55~125 CJEDEC JEITA TOSHIBA 2-4E1CWeight: 0.13 g (typ.) Electrical Characteristics (Ta == 25C) ==Characteristics Symbol Test Condition Min Typ. Max UnitGate cut-off current IGSS VGS = 25 V, VDS = 0 1.0 nAGate-drain breakdown voltage V (BR) GDS VDS = 0, IG = 100 A 25
