View 2sk2610 datasheet:

2SK2610 TOSHIBA Field Effect Transistor Silicon N Channel MOS Type (-MOSIII) 2SK2610 Chopper Regulator, DC-DC Converter and Motor Drive Applications Unit: mm Low drain-source ON resistance : RDS = 2.3 (typ.) (ON) High forward transfer admittance : |Y | 4.4 S (typ.) fs = Low leakage current : I = 100 A (max) (V = 720 V) DSS DS Enhancement-mode : Vth = 2.0~4.0 V (V = 10 V, I = 1 mA) DS DMaximum Ratings (Ta = 25C) Characteristics Symbol Rating UnitDrain-source voltage VDSS 900 VDrain-gate voltage (RGS = 20 k) VDGR 900 VGate-source voltage VGSS 30 VDC (Note 1) ID 5Drain current A Pulse (Note 1) IDP 15 1. GATE 2. DRAIN (HEAT SINK) Drain power dissipation (Tc = 25C) PD 150 W 3. SOURCE Single pulse avalanche energy EAS 595 mJ(Note 2)JEDEC Avalanche current IAR 5 AJEITA SC-65Repetitive avalanche energy (
