View 2sk2615 datasheet:

2SK2615 2 TOSHIBA Field Effect Transistor Silicon N Channel MOS Type (L --MOSV) 2SK2615 DC-DC Converter, Relay Drive and Motor Drive Unit: mmApplications Low drain-source ON resistance : RDS (ON) = 0.23 (typ.) High forward transfer admittance : |Yfs| = 2.0 S (typ.) Low leakage current : IDSS = 100 A (max) (VDS = 60 V) Enhancement mode : Vth = 0.8 to 2.0 V (VDS = 10 V, ID = 1 mA) Absolute Maximum Ratings (Ta = 25C) Characteristics Symbol Rating UnitDrain-source voltage VDSS 60 VDrain-gate voltage (RGS = 20 k) VDGR 60 VGate-source voltage VGSS 20 VDC (Note 1) ID 2Drain current A Pulse (Note 1) IDP 6Drain power dissipation PD 0.5 WJEDEC Drain power dissipation (Note 2) PD 1.5 WJEITA Channel temperature Tch 150 CTOSHIBA 2-5K1BStorage temperature range Tstg -55 to 150 C Weight: 0.05 g (typ.) Note 1: En
