View 2sk3090 datasheet:
2SK3090 TOSHIBA Field Effect Transistor Silicon N Channel MOS Type (-MOSVI) 2SK3090 Chopper Regulator DC-DC Converter, and Motor Drive Unit: mmApplications Low drain-source ON resistance : RDS (ON) = 16 m (typ.) High forward transfer admittance : |Yfs| = 26 S (typ.) Low leakage current : IDSS = 100 A (max) (VDS = 30 V) Enhancement mode : Vth = 1.5~3.0 V (VDS = 10 V, ID = 1 mA) Absolute Maximum Ratings (Ta = 25C) Characteristics Symbol Rating UnitDrain-source voltage VDSS 30 VDrain-gate voltage (RGS = 20 k) VDGR 30 VGate-source voltage VGSS 20 V DC (Note 1) ID 45 Drain current A Pulse (Note 1) IDP 135 Drain power dissipation (Tc = 25C) PD 60 WSingle pulse avalanche energy EAS 220 mJ(Note 2)JEDEC Avalanche current IAR 45 AJEITA Repetitive avalanche energy (Note 3) EAR 6 mJChannel temperature Tch 150 C
