View 2sk3098 datasheet:

2sk30982sk3098

Ordering number : EN86272SK3098SANYO SemiconductorsDATA SHEETN-Channel Silicon MOSFETGeneral-Purpose Switching Device2SK3098ApplicationsFeatures Low ON-resistance. High-speed switching. 15V drive.SpecificationsAbsolute Maximum Ratings at Ta=25CParameter Symbol Conditions Ratings UnitDrain-to-Source Voltage VDSS 400 VGate-to-Source Voltage VGSS 30 VDrain Current (DC) ID 12 ADrain Current (Pulse) IDP 48 AAllowable Power Dissipation PD Tc=25C85 WChannel Temperature Tch 150 CStorage Temperature Tstg --55 to +150 CElectrical Characteristics at Ta=25CRatingsParameter Symbol Conditions Unitmin typ maxDrain-to-Source Breakdown Voltage V(BR)DSS ID=1mA, VGS=0V 400 VZero-Gate Voltage Drain Current IDSS VDS=320V, VGS=0V 1.0 mAGate-to-Source Leakage Current IGSS VGS= 30V, VDS=0V 100 nACutoff Voltage VGS(off) VDS=10V
