View 2sk3099ls datasheet:

2sk3099ls2sk3099ls

isc N-Channel MOSFET Transistor 2SK3099LSFEATURESDrain Current : I = 9A@ T =25D CDrain Source Voltage: V =400V(Min)DSSStatic Drain-Source On-Resistance: R = 0.55(Max)DS(on)100% avalanche testedMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationDESCRIPTIONmotor drive, DC-DC converter, power switchand solenoid drive.ABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITV Drain-Source Voltage 400 VDSSV Gate-Source Voltage-Continuous 30 VGSI Drain Current-Continuous 9 ADI Drain Current-Single Pluse 36 ADMP Total Dissipation @T =25 35 WD C.75Max. Operating Junction Temperature -55~150 TJStorage Temperature -55~150 TstgTHERMAL CHARACTERISTICSSYMBOL PARAMETER MAX UNIT/WR Thermal Resistance, Junction to Case 3.57th j-c1isc websitewww.iscse
