SMD Type MOSFETN-Channel MOSFET2SK3224-ZTO-252Unit: mm+0.156.50-0.15+0.12.30 -0.1 Features +0.25.30-0.2 +0.80.50 -0.7 VDS (V) = 60V ID = 20 A (VGS = 10V) RDS(ON) 40m (VGS = 10V)0.127+0.10.80-0.1max RDS(ON) 60m (VGS = 4V) Low Ciss : Ciss = 790 pF TYP.+ 0.12.3 0.60- 0.11 Gate+0.154 .60 -0.15Drain2 Drain3 SourceBodyGate DiodeGateProtectionSourceDiode Absolute Maximum Ratings Ta = 25Parameter Symbol Rating Unit Drain-Source Voltage VDS 60V20(AC) Gate-Source Voltage VGS(DC) +20,-10 Continuous Drain Current ID 20A Pulsed Drain Current (Note.1) IDM 70 Single Avalanche Current (Note.2) IAS 10Tc = 25C 25 Power Dissipation PD WTa = 25C1 Single Avalanche Energy (Note.2) EAS 10 mJ Thermal Resistance.Junction- to-Ambient RthJA 125/W Thermal R
