View 2sk3228 datasheet:
2SK3228 Silicon N Channel MOS FET High Speed Power Switching REJ03G1094-0400 Rev.4.00 May 15, 2006 Features Low on-resistance RDS (on) = 6 m typ. Low drive current 4 V gate drive device can be driven from 5 V source Outline RENESAS Package code: PRSS0004AC-A(Package name: TO-220AB)D1. Gate2. Drain (Flange)G3. Source123SRev.4.00 May 15, 2006 page 1 of 7 2SK3228 Absolute Maximum Ratings (Ta = 25C) Item Symbol Value UnitDrain to source voltage VDSS 80 VGate to source voltage VGSS 20 VDrain current ID 75 ADrain peak current ID (pulse) Note 1 300 ABody-drain diode reverse drain current IDR 75 AAvalanche current IAP Note 3 50 AAvalanche energy EAR Note 3 181 mJChannel dissipation Pch Note 2 100 WChannel temperature Tch 150 C Storage temperature Tstg 55 to +150 C Notes: 1. PW 10 s, du
