View 2sk3565 datasheet:

2SK3565 TOSHIBA Field Effect Transistor Silicon N Channel MOS Type (-MOSIV) 2SK3565 Switching Regulator Applications Unit: mm Low drain-source ON resistance: RDS (ON) = 2.0 (typ.) High forward transfer admittance: |Yfs| = 4.5 S (typ.) Low leakage current: IDSS = 100 A (VDS = 720 V) Enhancement mode: Vth = 2.0 to 4.0 V (VDS = 10 V, ID = 1 mA) Absolute Maximum Ratings (Ta = 25C) Characteristics Symbol Rating UnitDrain-source voltage VDSS 900 VDrain-gate voltage (RGS = 20 k) VDGR 900 VGate-source voltage VGSS 30 V1: Gate DC (Note 1) ID 5 2: Drain Drain current A 3: Source Pulse (t = 1 ms) IDP 15 (Note 1) Drain power dissipation (Tc = 25C) JEDEC PD 45 WSingle pulse avalanche energy JEITA SC-67EAS 595 mJ(Note 2)TOSHIBA 2-10U1BAvalanche current IAR 5 AWeight : 1.7 g (typ.) Repetitive avalanche en
