View 2sk3871-01mr datasheet:

2SK3871-01MRN-CHANNEL SILICON POWER MOSFET Outline Drawings (mm) 200406TO-220FFUJI POWER MOSFETSuper FAP-G SeriesFeatures High speed switching Low on-resistance No secondary breakdown Low driving power Avalanche-proof Applications Switching regulators DC-DC converters UPS (Uninterruptible Power Supply)Maximum ratings and characteristicAbsolute maximum ratings(Tc=25C unless otherwise specified)Equivalent circuit schematicItem Symbol Ratings Unit RemarksDrain-source voltage VDS 230 VDrain(D)VDSX 230 VVGS=-30VContinuous Drain Current ID 40 APulsed Drain Current ID(puls] 160 AGate-Source Voltage VGS 30 VGate(G)Maximum Avalanche current IAR 40 ANote *1Non-Repetitive EAS 633.1 mJ Source(S)Note *2Maximum Avalanche Energy
