View 2sk3872-01l-s-sj datasheet:

2SK3872-01L,S,SJN-CHANNEL SILICON POWER MOSFET200406Outline Drawings (mm)FUJI POWER MOSFETSuper FAP-G SeriesFeatures High speed switching Low on-resistanceSee to P4 No secondary breakdown Low driving power Avalanche-proof Applications Switching regulators DC-DC converters UPS (Uninterruptible Power Supply)Maximum ratings and characteristicAbsolute maximum ratings(Tc=25C unless otherwise specified)Equivalent circuit schematicItem Symbol Ratings Unit RemarksDrain(D)Drain-source voltage VDS 230 VVDSX 230 VVGS=-30VContinuous Drain Current ID 40 APulsed Drain Current ID(puls] 160 AGate-Source Voltage VGS 30 V Gate(G)Maximum Avalanche current IAR 40 ANote *1Source(S)Non-Repetitive EAS 633.1 mJNote *2
