View 2sk3874-01r datasheet:

2SK3874-01RN-CHANNEL SILICON POWER MOSFET Outline Drawings (mm) 200406FUJI POWER MOSFETSuper FAP-G SeriesFeatures High speed switching Low on-resistance No secondary breakdown Low driving power Avalanche-proof Applications Switching regulators DC-DC converters UPS (Uninterruptible Power Supply)Maximum ratings and characteristicAbsolute maximum ratings(Tc=25C unless otherwise specified)Equivalent circuit schematicItem Symbol Ratings Unit RemarksDrain(D)Drain-source voltage VDS 280 VVDSX 280 VVGS=-30VContinuous Drain Current ID 56 APulsed Drain Current ID(puls] 224 AGate(G)Gate-Source Voltage VGS 30 VMaximum Avalanche current IAR 56 ANote *1Source(S)Non-Repetitive EAS 1039.1 mJNote *2Note *1:Tch
