View 2sk810 datasheet:

isc N-Channel MOSFET Transistor 2SK810FEATURESDrain Current : I = 14A@ T =25D CDrain Source Voltage: V = 100V(Min)DSSStatic Drain-Source On-Resistance: R = 0.18(Max) @ V = 10VDS(on) GS100% avalanche testedMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationDESCRIPTIONmotor drive, DC-DC converter, power switchand solenoid drive.ABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITV Drain-Source Voltage 100 VDSSV Gate-Source Voltage-Continuous 20 VGSI Drain Current-Continuous 14 ADI Drain Current-Single Pluse 56 ADMP Total Dissipation @T =25 60 WD CMax. Operating Junction Temperature -55~150 TJStorage Temperature -55~150 TstgTHERMAL CHARACTERISTICSSYMBOL PARAMETER MAX UNIT/WR Thermal Resistance, Junction to Case 2.083th j-c1isc website
