View 75nf75 datasheet:

75nf7575nf75

isc N-Channel MOSFET Transistor 75NF75DESCRIPTIONDrain Current I = 75A@ T =25D CDrain Source Voltage-: V = 75V(Min)DSSStatic Drain-Source On-Resistance: RDS(on) = 0.013(Max)Minimum Lot-to-Lot variations for robust deviceperformance and reliable operationAPPLICATIONSSolenoid and relay driversDC motor controlDC-DC converters DCAutomotive environmentABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITV Drain-Source Voltage 75 VDSSV Gate-Source Voltage-Continuous 20 VGSDrain Current-Continuous@T =25 75CI ADDrain Current-Continuous@T =100 60CI Drain Current-Single Pluse 300 ADMP Total Dissipation @T =25 200 WD CT Max. Operating Junction Temperature 150 JStorage Temperature -55~150 TstgTHERMAL CHARACTERISTICSSYMBOL PARAMETER MAX UNIT/WR Thermal Resistance,
