View a1015 datasheet:
A1015 -0.15A , -50V PNP Plastic-Encapsulated Transistor Elektronische Bauelemente RoHS Compliant Product A suffix of -C specifies halogen & lead-free TO-92 FEATURES Power Dissipation G H1Emitter 1112Collector 222J3Base 333CLASSIFICATION OF hFE A DMillimeter Product-Rank A1015-O A1015-Y A1015-GR REF. BMin. Max. A 4.40 4.70 Range 70~140 120~240 200~400 K B 4.30 4.70 C 12.70 - D 3.30 3.81 E 0.36 0.56 F 0.36 0.51 E C FG 1.27 TYP. H 1.10 - J 2.42 2.66 K 0.36 0.76 Collector 2 3 Base 1 Emitter ABSOLUTE MAXIMUM RATINGS (TA = 25C unless otherwise specified) Parameter Symbol Rating Unit Collector to Base Voltage V -50 V CBOCollector to Emitter Voltage VCEO -50 V Emitter to Base Voltage V -5 V EBOCollector Current - Continuous I -150 mA CCollector Power Dissipation P 400 mW
