View aok15b60d datasheet:
AOK15B60DTM600V, 15A Alpha IGBT with DiodeGeneral Description Product Summary VCE600VThe Alpha IGBTTM line of products offers best-in-class IC (TC=100C) 15Aperformance in conduction and switching losses, withrobust short circuit capability. They are designed for ease VCE(sat) (TC=25C) 1.6Vof paralleling, minimal gate spike under high dV/dtconditions and resistance to oscillations. The soft co-package diode is targeted for minimal losses in motorcontrol applications.100% Eon/Eoff Tested100% Qrr Tested100% Short Circuit Current Tested*Top ViewTop ViewC CTO-247TO-247GGEEEECCGGAOK15B60DAOK15B60DAbsolute Maximum Ratings TA=25C unless otherwise notedParameter Symbol AOK15B60D UnitsParameter Symbol AOK15B60D UnitsCollector-Emitter Voltage V 600 VCEGate-Emitter Voltage V 20 VGETC=25C 30Continuous
