View aotf18n65 datasheet:

aotf18n65aotf18n65

isc N-Channel MOSFET Transistor AOTF18N65FEATURESDrain Current I = 18A@ T =25D CDrain Source Voltage-: V =650V(Min)DSSStatic Drain-Source On-Resistance: R =0.39(Max)DS(on)100% avalanche testedMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationDESCRIPTIONDesigned for use in switch mode power supplies and generalpurpose applications.ABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITV Drain-Source Voltage 650 VDSSV Gate-Source Voltage-Continuous 30 VGSI Drain Current-Continuous 18 ADI Drain Current-Single Pluse 80 ADMP Total Dissipation @T =25 50 WD CT Max. Operating Junction Temperature -55~150 JStorage Temperature -55~150 TstgTHERMAL CHARACTERISTICSSYMBOL PARAMETER MAX UNIT/WR Thermal Resistance, Junction to Case 2.5th j-c1isc websi
