View ap2n7002ku datasheet:

ap2n7002kuap2n7002ku

AP2N7002KUHalogen-Free ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Simple Drive Requirement BVDSS 60VD Small Package Outline RDS(ON) 2 Surface Mount Device ID 270mAS RoHS Compliant & Halogen-FreeSOT-323GDDescriptionAP2N7002 series are from Advanced Power innovated designGand silicon process technology to achieve the lowest possibleon-resistance and fast switching performance. It provides thedesigner with an extreme efficient device for use in a wide rangeSof power applications.The SOT-323 package is widely used for all commercial-industrial applications.Absolute Maximum Ratings@Tj=25oC(unless otherwise specified).Symbol Parameter Rating UnitsVDS Drain-Source Voltage 60 VVGS Gate-Source Voltage +20 VDrain Current3, VGS @ 10VID@TA=25 270 mADrain Current3, VGS @ 10VID@TA=70
