View ap98t06gs-hf datasheet:

ap98t06gs-hfap98t06gs-hf

AP98T06GS-HFHalogen-Free ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFETD Simple Drive Requirement BVDSS 60V Lower Gate Charge RDS(ON) 5m Fast Switching Characteristic ID 80AG RoHS Compliant & Halogen-FreeSDescriptionAdvanced Power MOSFETs from APEC provide theGdesigner with the best combination of fast switching,DSTO-263(S)ruggedized device design, low on-resistance and cost-effectiveness.The TO-263 package is widely preferred for commercial-industrialsurface mount applications and suited for switching powerapplications.Absolute Maximum RatingsSymbol Parameter Rating UnitsVDS Drain-Source Voltage 60 VVGS Gate-Source Voltage +20 VContinuous Drain Current, VGS @ 10V3ID@TC=25 80 AIDM Pulsed Drain Current1 320 APD@TC=25 Total Power Dissipation 250 W TSTG Storage Temperature Ran
