View apt13gp120bg datasheet:

TYPICAL PERFORMANCE CURVES APT13GP120B_S(G) 1200V APT13GP120B APT13GP120S APT13GP120BG* APT13GP120SG**G Denotes RoHS Compliant, Pb Free Terminal Finish.BPOWER MOS 7 IGBTD3PAKSCThe POWER MOS 7 IGBT is a new generation of high voltage power IGBTs. Using Punch G EThrough Technology this IGBT is ideal for many high frequency, high voltage switching Gapplications and has been optimized for high frequency switchmode power supplies.CE Low Conduction Loss 100 kHz operation @ 600V, 10A Low Gate Charge 50 kHz operation @ 600V, 16AC Ultrafast Tail Current shutoff RBSOA RatedGEMAXIMUM RATINGS All Ratings: TC = 25C unless otherwise specified. Parameter UNITSymbol APT13GP120B_S(G)VCES Collector-Emitter Voltage1200VoltsVGEGate-Emitter Voltage30IC1Continuous Collector Current @ TC = 25C41IC2 Con
