View apt47n65bc3g datasheet:

APT47N65BC3600V 47A 0.070Super Junction MOSFETCOOLMOSPower SemiconductorsD3 Ultra low RDS(ON) Increased Power Dissipation Low Miller Capacitance Ultra Low Gate Charge, Qg Avalanche Energy Rated TO-247 or Surface Mount D3PAK PackageMAXIMUM RATINGS All Ratings: TC = 25C unless otherwise specified. Symbol Parameter APT47N65BC3 UNITVDSSDrain-Source Voltage 650 VoltsID Continuous Drain Current @ TC = 25C47 AmpsIDM Pulsed Drain Current 1141VGS Gate-Source Voltage Continuous20 VoltsVGSM Gate-Source Voltage Transient30Total Power Dissipation @ TC = 25C Watts417PDLinear Derating Factor W/C3.33TJ,TSTG Operating and Storage Junction Temperature Range -55 to 150CTLLead Temperature: 0.063" from Case for 10 Sec.260dv/dt Drain-Source Voltage slope (VDS = 480V, ID = 47A, TJ = 125C) V/n
