View auirf9540n datasheet:

auirf9540nauirf9540n

PD - 97626AUTOMOTIVE GRADEAUIRF9540NFeaturesl Advanced Planar TechnologyDl Dynamic dV/dT RatingV(BR)DSS-100Vl 175C Operating Temperaturel Fast SwitchingRDS(on) max.0.117Gl Fully Avalanche Ratedl Repetitive Avalanche AllowedID-23ASup to Tjmaxl Lead-Free, RoHS Compliantl Automotive Qualified*DDescriptionSSpecifically designed for Automotive applications,DGthis cellular design of HEXFET Power MOSFETsutilizes the latest processing techniques to achieveTO-220ABlow on-resistance per silicon area. This benefit AUIRF9540Ncombined with the fast switching speed andruggedized device design that HEXFET power G D SMOSFETs are well known for, provides the designerGate Drain Sourcewith an extremely efficient and reliable device for usein Automotive and a wide variety of other applications.Absolute Maximum RatingsStre
