View bc237 bc238 bc239 datasheet:

MOTOROLAOrder this documentSEMICONDUCTOR TECHNICAL DATAby BC237/DAmplifier TransistorsBC237,A,B,CNPN SiliconBC238B,CBC239,CCOLLECTOR12BASE3EMITTER1MAXIMUM RATINGS23BC BC BC237 238 239Rating Symbol UnitCASE 2904, STYLE 17TO92 (TO226AA)CollectorEmitter Voltage VCEO 45 25 25 VdcCollectorEmitter Voltage VCES 50 30 30 VdcEmitterBase Voltage VEBO 6.0 5.0 5.0 VdcCollector Current Continuous IC 100 mAdcTotal Device Dissipation @ TA = 25C PD 350 mWDerate above 25C 2.8 mW/CTotal Device Dissipation @ TC = 25C PD 1.0 WattsDerate above 25C 8.0 mW/COperating and Storage Junction TJ, Tstg 55 to +150 CTemperature RangeTHERMAL CHARACTERISTICSCharacteristic Symbol Max UnitThermal Resistance, Junction to Ambient RqJA 357 C/WThermal Resistance, Junction to Case RqJC 125 C/WELECTRICAL CHA
